Moulding Machine
MODEL | NV15 | NV35 | NV45 | NV60 | NV85 |
---|---|---|---|---|---|
INJECTION UNIT | |||||
Screw Diameter (mm) | 25 | 32 | 32 | 36 | 40 |
Injection Pressure (kg/cm2) | 1098 | 1107 | 1195 | 1312 | 1492 |
Shot Size (cm3) | 49 | 93 | 104 | 132 | 176 |
Shot Weight (PS) (g) | 44 | 85 | 96 | 122 | 164 |
Injection Rate (g/s) | 30 | 62 | 87 | 121 | 100 |
Injection Stroke (mm) | 100 | 116 | 120 | 140 | 160 |
No. of Thermocouple | 3 | 3+1 | 3+1 | 3+1 | 3+1 |
CLAMPING UNIT | |||||
Clamping Force (tons) | 15 | 35 | 45 | 55 | 85 |
Platen Size (mm) | 390*250 | 500*340 | 545*400 | 595*475 | 680*545 |
Space Between Tie-Bar (mm) | 275*135 | 360*200 | 410*250 | 460*330 | 510*360 |
Min. Mould Height (mm) | 80-140 | 60-145 | 150-200 | 180-300 | 230-330 |
Opening Stroke (mm) | 160 | 215 | 200 | 200 | 250 |
Max. Open Day Light (mm) | 300 | 275-360 | 350-400 | 380-500 | 480-580 |
Ejector Force (tons) | 1.3 | 1.3 | 2.7 | 2.7 | 4.6 |
Ejector Stroke (mm) | 40 | 35 | 40 | 40 | 50 |
OTHER | |||||
Max. Pump Pressure (kg/cm2) | 140 | 140 | 140 | 140 | 140 |
Oil Reservoir Capacity (Ltr) | 80 | 180 | 200 | 220 | 310 |
Pump Motor Power (KW) | 4(4) | (4) | 5.5 | 7.5 | 11 |
Heating Power (KW) | 2 | 2.4 | 4.75 | 5.55 | 5.95 |
Total Power (KW) | 6 | 6.4 | 10.25 | 13.05 | 16.95 |
Machine Weight (tons) | 0.89 | 1.4 | 2.3 | 2.8 | 3.6 |
Machine Size (m) | 1.3*0.8*2.1 | 1.5*0.9*2.3 | 1.7*1.3*2.7 | 1.8*1.4*3.0 | 2.0*1.5*3.4 |
Neelgiri Machinery Global Pvt. Ltd. is a leading manufacturer of various kinds of high-quality Moulding Machine Manufacturers, like moulds and screw barrels, toggle injection moulding, horizontal injection moulding, vertical injection moulding, plastic injection moulding, injection moulding machines, servo plastic injection moulding machines, etc. We manufacture national and international standard parameters using modern inputs and the most advanced technology with highly skilled professional team. These products find application in various industries for several functions.
Molding machine manufacturers are responsible for designing, developing, and manufacturing all kinds of moulds that are used in plastic injection molding. Molding machines are used to produce a variety of plastic products from plastic injection moulds. We also provide the machinery that is required for producing such molds. if you want to know about our products and services, contact us, and our team will assist you according to your requirements.
